KPGPS24 is the latest 4G GPS tracker support LTE/WCDMA/UMTS.

Description

KPGPS24 is the latest 4G GPS tracker support LTE/WCDMA/UMTS.This device can locate and monitor any remote targets by SMS/PC/APP. The user also can remote cut off oil/power and check the historical record.

The unit features excellent and stable work performance.It used for vehicle tracking and fleet management.

---

Functions

• 4G LTE network support
• Real-time position inquire
• Vehicle trip history on web
• SOS alarm
• ACC switch alarm
• Geo-fence alarm
• External power cut off alarm
• Remote cut off fuel/power (optional)
• Vehicle towing alarm
• Overspeed alarm
• Backup battery low power alarm
• Car battery low power alarm
• High temperature alarm
• Power saving mode
• Mileage report
• Camera(optional for ODM only)
• Door sensor(optional for ODM only)
• Fuel sensor(optional for ODM only)

Applications

• Yachts and Boats tracking
• Vehicle/Truck tracking
• Asset security
• Fleet Management

Advantages

• Qualcomm 4G LTE chip
• Global Frequency is optional
• U-BLOX7 GPS chipset
• Unique design and multiple color to optional
• IOS & Android support
• Protocol is open and compatible other third party platform
• White Label

Specification

Dimension	90(L)*70(W)*24(H)mm
Weight	138g
Input Voltage	12-36 VDC
Backup battery	3.7V 500 mAh
Power Consumption	50mA standby current at 12 V
Working hours	10 hours in power-saving mode, 4 hours in normal mode
4G Frequency bands	KPGPS24-A (US/Canada/Mexico) 4G LTE: B2/B4/B12 3G WCDMA: 850/1700/1900MHz KPGPS24-E (Europe/Asia/Africa) 4G LTE: B1/B3/B7/B8/B20/B28A 3G WCDMA : 900/2100MHz 2G: 900/1800MHz KPGPS24-AU (Australia/New Zealand) 4G LTE: B1/B2/B3/B4/B5/B7/B8/B28/B40 3G WCDMA: 850/900/1900/2100MHz 2G :850/900/1800/1900MMz Note: Select correct device according to your local frequency bands.
GPS sensitivity	-162dBm
Channel	56
Positioning Accuracy	10m
Cold Start	30s
Warm start	15s
Hot start	1s
Working temperature	-20°C to +60°C
Humidity	5% to 95% non-concretion
Antenna	external 4G/GPS antenna
Sensor	3D accelerometer sensor
LED	4G(blue), GPS(green), Power(red)
SIM Card interface	Standard Size SIM
Certificate	CE/NBTC/NTC/Vodafone

Package

• 1* KPGPS24 4G GPS Tracker
• 1* GPS Antenna
• 1* 4G Antenna
• 1* Power wire
• 1* SOS Button
• 1* SIM Card tray
• 1* User Manual

PRICE

KPGPS24-E　　　＄800

KPGPS24-AU　　＄820

KPGPS24-NB　　＄850

Discounts are available depending on the number of units purchased. Please request an accurate quote including shipping charges.

---

Support

KPGPS24

Comprehensive support plan for equipment operation and management

※トラッキングの写真いくつか

This plan provides comprehensive support for the operation and management of installed equipment using KPGPS24 and the GPS tracking platform. We provide comprehensive support, from the initial settings required for installation and installation, to customer registration, to remote engine stop and recovery, which can be performed by connecting this device and platform, to obtaining location information of the installed vehicle. . The entrusted content differs for each plan below. Please check the plan for details.

---

Plan

Plan Light ＄820

・Device initial settings　＄700

・Platform Customer initial Setup – Location Tracking – Fees ＄80

・Includes IoT dedicated SIM fee $20 (36 months)

・Device control 10-dose package ＄20

※per additional device control　＄5

Plan Standard ＄1100

・Device initial settings　＄700

・Platform Customer initial Setup – Location Tracking, Engine Stop/Restart – Fees ＄340

・Includes IoT dedicated SIM fee $30 (48 months)

・Device control 20-dose package ＄30

※per additional device control　＄5

Plan Premium ＄1400

・Device initial settings　＄700

・Platform customer initial setup – location tracking, driving history storage, engine stop/restart – Fees

 ＄620

・Includes IoT dedicated SIM fee $40 (60 months)

・Device control 30-dose package ＄40

※per additional device control　＄5

You can create your own discount plan depending on the number of monthly contracts. Request an accurate quote.
